HT15 Mini Excavator Parpmeter
| Model:HT15 | Main Demensions | Operating Range | |||||
| Weight | 1200kg | Overall dimension ( LxWxH) | 2550x940x1380 mm | Max. Digging depth | 1650 mm | ||
| Digging bucket capacity | 0.025cbm/120kg | Wheelbase | 770mm | Max. Vertical digging depth | 1800 mm | ||
| Bucket width | 380mm | Total length of track | 1090mm | Max. Digging height | 2610 mm | ||
| Engine | Laidong KM385 | Platform ground clearance | 380 mm | Max. Dumping height | 1850 mm | ||
| Platform back turning radius | 733 mm | Max. Digging radius on ground | 2850 mm | ||||
| Rated power | 18kw/3000r/min | Chassis width | 940 mm | Min. Rotation radius | 1330 mm | ||
| Displacement | 1617 ccm | Track width | 180 mm | Max. Upgrade height of bulldozer blade | 345 mm | ||
| Travel speed | 3.5km/h | Chassis ground clearance | 380 mm | Max. Digging depth of bulldozer blade | 255 mm | ||
| Track height | 320 mm | ||||||
